Heed Audio Questar (MM or MC) Phonostage

Heed Audio Questar (MM or MC) Phonostage

High Quality Moving Magnet (MM)/ (MC) Phonostage.

Please Note: the Heed Audio Questar Does Not come with a PSU but there is PSU Options to choose from.

The Heed Audio Questars are destined to be the best entry-level options of the Heed Audio modular line for vinyl reply that money can buy. Under the hood of their hefty, shielded steel chassis beats the heart of the Heed Audio Quasar MM/MC phonostage, conveniently divided into neatly-specialized a’ la carte portions.

The Heed Audio QUESTAR MM largely incorporates the Heed Audio Quasar’s unsurpassed MM circuitry, while its sibling, the Heed Audio Questar MC deploys a streamlined version of the Heed Audio Quasar’s MC stage, eliminating the need for jumper switches by optimising the amplifier to suit the 300-600 µV/100 Ohm output range characterising the vast majority of today’s moving coils. Considering its generous 18 dB headroom, ideal cartridge matching is virtually assured.

The internal construction of the Heed Audio Questars meets the most critical high-end standards in every respect. The amplifier employs an entirely dual-mono configuration and uses a two-stage – passive/active – RIAA equalisation. Gain adjustment has been optimised for maximum headroom and highest signal-to-noise ratio. Component parts are selected to exacting tolerances matching those of our Quasar.

The Heed Audio Questars are suitable for any line-level amplifier input, and can easily drive virtually any length of interconnect. There is no internal wiring or binding, and all high-current parts of the circuit are shielded. Both models feature gold-plated RCA terminals soldered directly onto the PCB, limiting all signal paths to a bare minimum.

The Heed Audio Questars (both MC/MM) now utilise improved external power supplies (optional extra) to avoid undesirable electro-magnetic interference within the chassis. The Heed Audio X-PSU 30 is a simple but vital part of performance improvement from the previous incarnations, and represents another example of how Heed take time and care to adapt and enhance their products continually.

Sonic performance can be even further enhanced by upgrading to the Heed Audio Quasar's substantial separate box 'Q-PSU' (optional extra) constructed around a massive 60 VA toroidal transformer with low-density magnetic field and minimal dispersion. With substantial 40,000 µF capacitor filtering, the 'Q-PSU' can feed the Heed Audio QUESTAR'S circuitry with the kind of super-clean current usually delivered only by battery-based supplies, even with extreme dynamic swings.

Available in a black casing with black fascia.

Features:

2-stage topology

Discrete bipolar transistor circuits

New improved in-line power supply

Power supply options available.
